Description
Technical Specifications
Built for sustained pulling power and reliability.
| Key Performance Metric | Specifications |
| Towing Capacity | 2.0T / 3.0T / 5.0T / 10.0T |
| Rated Drawbar Pull | 500N – 2500N (Continuous) |
| Drive Motor | High-Torque AC Maintenance-Free Motor |
| Travel Speed (Unloaded) | Up to 12.0 km/h |
| Battery Type | 24V or 48V Industrial Battery (Lithium Optional) |
| Turning Radius | Ultra-tight (Zero-turn capable on 3-wheel models) |
| Coupler Type | Multi-level Hitch / Automatic Pin (Customizable) |
Why Our Electric Tuggers Lead the Industry?
■ High-Torque AC Drive System
Equipped with a vertical AC brushless motor, our tractors provide smooth, stepless acceleration and powerful starting torque. The regenerative braking system not only ensures safety on ramps but also feeds energy back into the battery, extending shift life.
■ Advanced Ergonomics & Safety
-
Electric Power Steering (EPS): Standard on sit-on models, allowing for effortless control during long shifts.
-
Automatic Speed Reduction: The system senses sharp turns and automatically reduces speed to prevent trailer jackknifing.
-
Inching Control: Convenient buttons at the rear allow the operator to move the tractor slowly while standing next to the hitch, making trailer coupling a one-person job.
■ Universal Coupling Versatility
We offer a wide range of hitch and tow-ball configurations. Our multi-level rear hitch ensures compatibility with various trailer heights, ensuring your existing fleet of carts can be integrated immediately.
■ Compact & Robust Chassis
Built with a heavy-duty reinforced steel chassis and high-elasticity solid rubber tires, our tractors are designed for 24/7 industrial use. The compact 3-wheel design allows for a turning radius as small as 1200mm, ideal for navigating congested production lines.
Primary Applications
-
Manufacturing & Automotive: Supplying parts to assembly lines using a “train” of trailers.
-
Airports & Terminals: Efficient baggage and cargo dolly transport.
-
Hospitals & Large Facilities: Moving waste bins, linen carts, and heavy supplies quietly.
-
E-commerce Warehouses: Transporting large batches of picked orders to the packing zone.
Why Choose Our Towing Solutions?
As a specialist in industrial handling systems, we provide more than just the tractor:
-
System Integration: We can design and manufacture the matching industrial trailers/carts for a complete one-stop solution.
-
Battery Flexibility: Choose between standard lead-acid for economy or Lithium-ion for fast-charging, multi-shift operations.
-
Custom Engineering: Need a specific hitch height or a specialized weather cabin for outdoor use? Our engineering team can customize the tractor to your exact requirements.
FAQ
Q: What is the difference between Towing Capacity and Drawbar Pull?
A: Towing Capacity refers to the total weight of the trailers and load you can pull. Drawbar Pull is the actual force the tractor exerts. Our spec sheets provide both to help your engineers calculate ramp performance.
Q: Can these tractors be used outdoors?
A: Yes. We offer models with semi-enclosed or fully enclosed cabins and specialized tires for outdoor asphalt or concrete surfaces.
Q: Is a special license required to operate an electric tugger?
A: Generally, they are easier to operate than forklifts as there is no lifting involved. However, we recommend site-specific training, especially when navigating “trains” of multiple trailers.
