Description
Technical Specifications
Precision-built for daily industrial use.
| Feature | Specification Details |
| Load Capacity | 1500kg / 2000kg |
| Drive Type | Electric (Motorized) |
| Lift Type | Manual Hydraulic |
| Battery | 24V / 20Ah Lithium (Maintenance-Free) |
| Driving Motor | 0.65kw DC Brushless Motor |
| Travel Speed | 4.0 – 4.5 km/h (Loaded/Unloaded) |
| Fork Dimensions | 550/685mm (Width) x 1150mm (Length) |
3. Why Choose Our Semi-Electric Model?
■ Powerful Motorized Drive
No more straining to get a 1.5-ton load moving. The integrated high-torque motor handles the heavy pulling, reducing the risk of workplace musculoskeletal injuries. The stepless speed control allows for smooth acceleration even in tight spaces.
■ Long-Lasting Lithium Battery (Plug & Play)
We use a lightweight lithium battery that can be swapped in seconds. Unlike lead-acid batteries, these require zero maintenance and support “opportunity charging”—just plug it in during your break.
■ The “Manual Lift” Advantage
Why keep the lift manual? By removing the heavy electric lifting motor and large battery bank, the truck is lighter and more compact. It can enter elevators and delivery trucks that full-electric models are too heavy for. Plus, it significantly reduces the purchase price and maintenance complexity.
■ Ergonomic & Safety Handle
-
Emergency Stop: A large “belly button” reverse switch prevents the operator from being pinned.
-
Compact Turning: The handle can operate at a near-vertical angle, perfect for narrow aisles and containers.
4. Semi-Electric vs. Full-Electric: Which One to Choose?
| Feature | Semi-Electric | Full-Electric |
| Best For | Medium frequency / Light duty | High frequency / Multi-shift |
| Investment | Low / High ROI | High initial cost |
| Weight | Lightweight (approx. 140kg) | Heavier (approx. 200kg+) |
| Maintenance | Very Simple | Requires specialized tech |
5. Applications
-
Retail Stores: Moving pallets from the backroom to the shop floor quietly.
-
Delivery Trucks: Ideal for drivers who need a motorized aid that fits on a liftgate.
-
Manufacturing: Transporting components between workstations.
6. FAQ (Optimized for SEO)
Q: Can I still move the truck if the battery dies?
A: Yes! Because the lift is manual, you can still lower the forks and pull the truck manually like a traditional hand pallet jack in an emergency.
Q: Is it difficult to maintain the hydraulic system?
A: Not at all. It uses the same reliable hydraulic pump technology as our manual series. Regular oil checks and greasing of the joints are all it takes to keep it running for years.
Q: How do I charge the battery?
A: Every unit comes with an external smart charger. Simply remove the lightweight battery and plug it into any standard 110V/220V wall outlet.
