Description
Our advantage
1. Fully Sealed & Heated Ergonomic Cabin (The Extreme -25°C Life-Pod)
Constant Thermal Control: Features a fully insulated structural cabin equipped with high-output constant-temperature heaters to keep operators warm and highly focused throughout intensive shifts.
Zero-Fog Dual-Glazed Windows: Designed with double-glazed, vacuum-insulated heated safety glass. This prevents dynamic fogging and condensation when traveling between the freezing cold storage room and warm loading docks.
2. Advanced Anti-Condensation & Anti-Freezing Engineering
Moisture Shield Technology: All micro-controllers, electrical harnesses, and sensor connectors undergo rigorous anti-condensation sealing to prevent water-droplet short circuits during temperature transitions.
Low-Viscosity Hydraulics: Fitted with specialized low-temperature hydraulic fluid, Arctic-grade oil seals, and low-temp grease, ensuring lightning-fast valve response times even in deep-freeze states.
3. Synchronous Man-Up View & 180° Turret Assembly
Zero Ground-to-Air Blind Spots: The operator elevates with the mast, maintaining a perfect, eye-level flat perspective with the cold storage racks for flawless pallet picking.
180° Rotating Forks: The forks pivot smoothly 180 degrees to deposit and retrieve pallets left and right, completely eliminating the need for wide, energy-wasting turning lanes.
4. 80V High-Voltage Battery & Fleet Guidance Systems
Deep-Freeze Battery Optimization: Available with heavy-duty insulated Lead-Acid cells or optimized 80V Lithium-Ion packages with smart thermal heating matrices to prevent battery capacity drop-off in cold environments.
Automatic Guidance Integration: Fully compatible with electromagnetic wire guidance or mechanical guide rails, locking the truck into the aisle for high-speed automated steering inside the dark cold storage vault.
Technical Data
| Technical Parameter | Cold Store Specification Value (Model: MCC16U-CS) |
| Operating Temperature Rating | Continuous operation down to -25°C (-13°F) |
| Power Supply System | High-Voltage 80V (Low-Temp Active-Heating Lithium / Lead-Acid) |
| Operation Position | Man-Up Sealed & Heated Thermal Cabin |
| Rated Load Capacity (Q) | 1,600 kg (1.6 Tons) |
| Maximum Lifting Height (h3) | 15,000 mm / 16,500 mm / 17,500 mm / 18,500 mm |
| Minimum Operating Aisle Width | As narrow as 1,650 mm (Pallet size dependent) |
| Steering Control System | Pure Electric EPS / Wire-Guidance & Rail-Guidance Compatible |
| Cabin Glass Configuration | Double-Glazed Vacuum-Insulated Safety Glass with Integrated Defrosters |
