Description
🛠️ Key Product Selling Points
1. Outrigger-Free Engineering for Universal Pallet Handling
100% Closed Pallet Friendly: The absence of grounding straddle legs means the MBB series handles both open single-faced and closed double-sided block pallets without frame interference.
Container & Ground Staging Agility: Perfect for driving straight into low-overhead shipping containers to extract pallets or staging materials on tight manufacturing floors where structural base legs cannot fit under processing machinery.
2. Professional Heavy Lifting Up to 5.5M with Full Free Lift
Rigid High-Level Stacking: Available with structural Duplex and Triplex Full Free Mast configurations, providing smooth, deflection-free vertical handling up to 5500 mm.
Low Overhead Clearance Optimization: The Triplex Full Free Mast variant allows the forks to raise significantly before the overall mast extends upward, making it ideal for low-ceiling storage mezzanines.
3. Ergonomic Stand-On Riding with Deceleration Protection
High-Speed Transit Safety: Delivers productive travel speeds up to 6.0 km/h. The cushioned foldable pedal and side arm protectors feature an automatic deceleration system that reduces travel speed during tight high-altitude adjustments to protect operators.
Ergonomic Command Handle: The integrated control tiller combines lift, lower, travel direction, and an emergency stop button into a single interface for intuitive, one-handed operation.
4. Maintenance-Free AC Drive & Heavy Industrial Durability
Brushless Motor Matrix: Outfitted with a high-torque, maintenance-free AC drive motor that eliminates carbon brush replacement costs and maximizes uptime.
Waterproof & Dustproof Electrical Seals: All critical wiring looms utilize sealed industrial connectors to prevent dust buildup and moisture intrusion, ensuring reliable all-weather operation in busy textile or manufacturing environments.
📊 Industrial Standard Technical Data Table
| Model Variant | MBB10 (1.6M–3.5M) | MBB16 (Duplex / Triplex) | MBB20 (Duplex / Triplex) |
| Power Train Type | Industrial Battery | Industrial Battery | Industrial Battery |
| Driving Architecture | Stand-on (Foldable Pedal) | Stand-on (Foldable Pedal) | Stand-on (Foldable Pedal) |
| Rated Capacity | 1000 kg | 1600 kg | 2000 kg |
| Load Center | 500 mm | 500 mm | 500 mm |
| Service Weight (incl. battery) | 1680 – 1820 kg | 2300 – 2500 kg | 2550 – 2750 kg |
| Lifting Height | 1600 / 2500 / 3000 / 3500 mm | Up to 5500 mm | Up to 5500 mm |
| Overall Length | 2560 mm | 2765 mm | 2990 mm |
| Chassis Width | 994 mm | 900 / 1100 mm | 900 / 1190 mm |
| Fork Dimensions | 1070 * 100* 35mm | 1070 * 100* 35mm | 1070 * 122 * 40mm |
| Adjustable Fork Spread | 220 mm – 610 mm | 220 mm – 710 mm | 264 mm – 732 mm |
| Turning Radius | 1415 mm | 1590 mm | 1730 mm |
| Travel Speed (Laden / Unladen) | 4.0 / 5.8 km/h | 5.5 / 6.0 km/h | 5.5 / 6.0 km/h |
📈 Ideal Industry Application Scenarios
Closed Pallet Distribution Centers: Stacking heavy double-sided pallets into medium-high vertical racks where straddle-leg clearance is unavailable.
Cross-Dock Container Logistics: Driving directly into shipping container profiles to quickly pull out heavy cargo pallets and stage them on the loading dock.
Heavy Component Assembly Plants: Delivering 2.0-ton loads of raw industrial materials or textile rolls directly to production line assembly fields with high efficiency.
