Description
🛠️ Key Product Selling Points
1. 3-Wheel Zero-Radius Maneuverability
Pivot-Turn Agility: The advanced 3-wheel configuration allows the rear steering wheel to turn up to 90 degrees, enabling the forklift to literally rotate on its own axis. This slices the required aisle space down significantly compared to 4-wheel trucks.
Container Loading Ready: Optimized chassis dimensions and an available free-lift mast setup let the MN18 drive straight into freight containers or box trucks for rapid side-by-side pallet destacking.
2. High-Torque Dual AC Drive Matrix
Powerful Dual-Motor Traction: Equipped with independent AC drive motors supplying continuous power directly to the front wheels. The onboard computer dynamically calculates differential wheel speeds during cornering, preventing tire scrubbing and delivering exceptional ramp gradeability.
Regenerative Braking Systems: Automatically recaptures kinetic energy during deceleration and plug-braking, channeling current back to the battery pack to extend operational uptimes per shift.
3. Ergonomic Safety & Clear-View Mast Architecture
Wide-View Mast Geometry: Precision-engineered chains and hydraulic cylinder positionings ensure an exceptionally wide field of forward vision, allowing drivers to track fork tips and structural thresholds instantly.
Operator Centric Control Hub: Features a premium adjustable suspension seat, responsive multi-valve hydraulic levers, and a smart LCD diagnostic dashboard displaying real-time wheel steering angles and battery status.
4. Flexible Energy Architecture (Lithium-Ion / Lead-Acid)
Fast Charging Lithium Support: Available with high-density Lithium-ion battery packs that support rapid opportunity charging, letting your fleet run continuous multi-shift operations without long battery swap intervals.
📊 Industrial Standard Technical Data Table
| Technical Parameter | Specification Value (MiMA MN18) |
| Brand / Manufacturer | MiMA |
| Model Designation | MN18 (3-Wheel Series) |
| Power System | Pure Electric (High-Capacity Lithium-Ion / Industrial Lead-Acid) |
| Operator Configuration | Sit-Down Seated Counterbalance |
| Rated Load Capacity ($Q$) | 1800 kg (4,000 lbs) |
| Load Center Distance ($C$) | 500 mm |
| Wheelbase ($y$) | 1340 mm |
| Mast Configurations | 2-Stage Standard / 2-Stage Full Free Lift / 3-Stage Triplex |
| Standard Maximum Lift Height ($h_3$) | 3,000 mm up to 4,800 mm options |
| Free Lift Height ($h_2$) | Up to 1530 mm (Depending on mast package) |
| Chassis Width ($b_1$) | 1070 mm (Sleek footprint for tight stacking) |
| Turning Radius ($Wa$) | 1520 mm (Ultra-short pivot circle) |
| Travel Speed (Laden / Unladen) | 12.0 / 14.0 km/h |
| Lift Speed (Laden / Unladen) | 0.31 / 0.43 m/s |
| Drive Motor Power (AC) | Dual Efficient Motors System |
| Brake Execution | Hydraulic Foot Brake + Automatic Electromagnetic Parking Brake |
📈 Ideal Industry Distribution & Cross-Docking
Freight Forwarding & Container Destacking: Driving right past threshold ramps into shipping containers to load or pull heavy dual-stacked pallets.
Manufacturing Supply Lines: Feeding heavy parts bins and materials onto active production lines inside compact workshop aisles.
Food, Beverage & Cold Storage: Moving delicate, dense stock without emitting any toxic fumes, preserving air hygiene inside temperature-controlled rooms.
