Description
Technical Specifications
Precision engineering for smooth operation.
| Feature | Details & Specifications |
| Common Names | Hand Pallet Truck / Pallet Trolley / Pallet Jack |
| Load Capacity | 2500kg / 3000kg / 5000kg |
| Lowered Fork Height | 75mm (Low Profile) / 85mm (Standard) |
| Max. Lift Height | 190mm / 200mm |
| Fork Width (Overall) | 550mm (Narrow) / 685mm (Wide) |
| Fork Length | 1150mm / 1220mm (Customizable) |
| Pump Type | Integrated Casting Hydraulic Pump (Leak-Proof) |
| Wheel Material | Polyurethane (PU) or Heavy-Duty Nylon |
Why Our Hand Pallet Trolleys Lead the Market?
■ Leak-Proof Integrated Hydraulic Pump
The heart of our pallet truck is the one-piece integrated casting pump. Unlike welded pumps that are prone to oil leaks over time, our casting design ensures a sealed hydraulic circuit, extending the service life and reducing maintenance costs.
■ Reinforced “C-Channel” Steel Frame
We use thickened 3.75mm – 4mm high-grade steel for the fork frames. The reinforced C-channel design prevents the forks from bending or warping even when carrying maximum rated loads, a common issue with cheaper, lightweight alternatives.
■ Dual Wheel Options for Any Floor
-
Polyurethane (PU) Wheels: Ideal for epoxy or tiled floors. They are quiet, absorb vibration, and leave no marks.
-
Nylon Wheels: Best for hard, rough, or outdoor surfaces. They offer the lowest rolling resistance for easier movement of heavy loads.
■ Ergonomic 3-Position Handle
Our handle features a comfortable rubber grip and a 3-position control lever (Raise, Neutral, Lower). The “Neutral” position allows the operator to steer the trolley without resistance from the hydraulic pump, significantly reducing effort during transport.
Key Applications
-
Logistics & Distribution: Rapid cross-docking and pallet movement.
-
Manufacturing: Transporting raw materials and finished products between production lines.
-
Retail & Grocery: Safe and quiet stocking of store shelves.
-
Cold Storage: (Optional) Stainless steel or galvanized versions available for damp or refrigerated environments.
Maintenance Tips for Long-Lasting Use
To ensure your Hand Pallet Trolley serves you for years, we recommend:
-
Avoid Overloading: Always stay within the rated capacity to protect the hydraulic seals.
-
Regular Greasing: Keep the 12 grease nipples lubricated for smooth pivot movement.
-
Correct Pumping: Always pump the handle fully to ensure uniform pressure within the cylinder.
FAQ (Optimized for Search Indexing)
Q: What is the difference between a Pallet Truck and a Pallet Trolley?
A: They are the same product. “Pallet Truck” is more common in the US and international trade, while “Pallet Trolley” is a frequently used term in the UK, Australia, and India.
Q: Can you customize the fork length for special pallets?
A: Yes. As a manufacturer, we can produce extra-long forks (up to 2500mm) or extra-wide forks to accommodate specialized industrial equipment.
Q: Why is the “Neutral” setting on the handle important?
A: The neutral setting disengages the pump. This means when you pull the trolley, you aren’t fighting hydraulic pressure, making it much easier to move and extending the life of the internal valves.
